BA 2B Stainless Steel 316 Tube 150mm Polished Annealed Pickled Brighted
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Product Name | Welded Stainless Steel 316 Tube SS Pipes 150mm Large Diameter | Length | 2000mm, 2500mm, 3000mm, 5800mm, 6000mm, 12000mm, As Required |
|---|---|---|---|
| Outer Diameter | 6-2500mm， (3/8"-100") | Thickness | 0.3-150mm，(SCH10-XXS) |
| Grade | 316 | Type | Welded |
| Standard | ASTM, AISI, JIS, DIN, GB | Surface | BA, 2B, Polished |
| Price Term | CIF, FOB, CFR, EXW | Application | Construction, Kitchenware, Industry, Etc. |
| High Light | BA 2B Stainless Steel 316 Tube,Stainless Steel 316 Tube 150mm,150mm polished 316 stainless steel tube |
||
Product Description
Welded Stainless Steel 316 Tube SS Pipes 150mm Large Diameter
Seamless tube is extruded and drawn from a billet while welded tube is produced from a strip that is roll formed and welded to produce a tube.
Welded tube is considerably less expensive than seamless tube and is readily available in long continuous lengths.
Joining two pieces of dissimilar metals can be somewhat tricky; however, TIG, MIG and stick welding are all capable of successfully welding steel pipe to stainless steel pipe.
Stainless Steel Decorative Welded Pipe/Tube Production Process.
Stainless Steel Industrial Welded Pipe/Tube Production Process.
| Item | Welded Stainless Steel 316 Tube SS Pipes 150mm Large Diameter | |
| Steel grade | 200 series, 300 series, 400 series, 316 series, 904, etc | |
| Standard | ASTM A213, A312, ASTM A269, ASTM A778, ASTM A789, DIN17456, DIN17457 ,DIN17459, JIS G3459, JIS G3463, GOST9941, EN10216, BS3605, GB13296 | |
| Material | 304/L, 309S, 310S, 316/L, 317, 317L, 321, 347, 347H, 201, 410, 430, 420 | |
| Surface | Polishing, annealing, pickling, bright | |
| Type | hot rolled and cold rolled | |
| stainless steel round pipe/tube | ||
| Size | Wall thickness | 1mm-150mm(SCH10-XXS) |
| Outer diameter | 6mm-2500mm (3/8"-100") | |
| stainless steel square pipe/tube | ||
| Size | Wall thickness | 1mm-150mm(SCH10-XXS) |
| Outer diameter | 4mm*4mm-800mm*800mm | |
| stainless steel rectangular pipe/tube | ||
| Size | Wall thickness | 1mm-150mm(SCH10-XXS) |
| Outer diameter | 6mm-2500mm (3/8"-100") | |
| Length | 4000mm, 5800mm, 6000mm, 12000mm, or as required. | |
| Trade terms | Price terms | FOB, CIF, CFR, CNF, Ex-work |
| Payment terms | T/T, L/C, | |
| Delivery time | Prompt delivery or as the order quantity. | |
| Export to |
Ireland, Singapore, Indonesia, Ukraine, Saudi Arabia, Spain, Canada, USA, Brazil, Thailand, Korea, Italy, India, Egypt, Oman, Malaysia, Kuwait, Canada, Viet Nam, Peru, Mexico, Dubai, Russia, etc |
|
| Package | Standard export seaworthy package, or as required. | |
| Application |
Widely used in petroleum, foodstuff, chemical industry, construction, electric power, nuclear, energy, machinery, biotechnology, paper making, shipbuilding, boiler fields. Pipes also can be made according to the customer's required. |
|
| Container size |
20ft GP:5898mm(Length)x2352mm(Width)x2393mm(High) 24-26CBM 40ft GP:12032mm(Length)x2352mm(Width)x2393mm(High) 54CBM 40ft HC:12032mm(Length)x2352mm(Width)x2698mm(High) 68CBM |
|
Available Specification
| Product Name | Executive Standard | Dimension | Steel Code / Steel Grade |
| Industrial Pipes | ASTM A312, A358, A778 JIS G3459 |
OD: 1/4"~40" WT: SCH5S~SCH80S |
TP304, TP304L, TP316L, SUS304TP |
| Tubes for Boiler and Heat-Exchanger, General Service Tubing | ASTM A249, A269, JIS G3463 | OD: 15.9~139.8mm WT: 1.6~5.0mm |
TP304, TP304L, TP316L, SUS304TB |
| Mechanical and Structural Tubes | ASTM A554, JIS G3446 | OD: 7.9~152.4mm WT: 0.5~6.5mm |
MT304, MT304L, MT316L, MT430 Grade 201, 202 as per mill's STD SUS304 |
| Square Tubes | ASTM A554 | OD: 12.7x12.7~150x150mm WT: 0.7~6.5mm |
MT304, MT304L, MT316L, MT430 Grade 201, 202 as per mill's STD |
| Rectangular Tubes | ASTM A554 | OD: 10x20~100x200mm WT: 0.7~6.5mm |
MT304, MT304L, MT316L, MT430 Grade 201, 202 as per mill's STD |
| Sanitary Tubing | ASTM A270 JIS G3447 |
OD: 25.4~165.2mm WT: 0.8~3.05mm |
TP304, TP304L, TP316L, SUS304TBS |
| Large Gauge Pipes for Ordinary Piping | JIS G3448 | OD: 15.88~318.5mm WT: 0.8~3.0mm |
SUS304TPD |
| Large Diameter Pipes | JIS G3468 | OD: 14"~40" WT: SCH5S~SCH40S |
SUS304TPY |
1. How can I get a quotation from you?
You can leave us message or send us a email and we will reply every message in time.
Or we may talk on line by skype & wechat.
And you can also find our contact information on contact page.
2. Can I get samples before order?
Yes, of course. Can send you small piece for you to check quality.
3. What is your delivery time?
A. The time of delivery is usually around 7-25 days according to the products you need.
4. What is your payment terms?
Our usual payment term is 30% deposite, and rest against B/L.
L/C is also acceptatble .
5. How can you garantee what I got will be good?
First of all, the material origin in TISCO, JISCO, etc and we can offer MTC from the steel mill.
Also, we accept third-party test.
6. How do you make our business long-term and good relationship?
A. We keep good quality and competitive price to ensure our customers benefit ;
B. We respect every customer as our friend and we sincerely do business and make friends with them no matter where they come from
Looking for ideal Stainless Steel Pipe Tube supplier ? We have a wide selection at good prices to help you get creative. All the SS pipes are quality guaranteed. We are China Origin Factory of Customized SS tube. If you have any question, please feel free to contact us.
